ZAULaS INVERTER CATALOGUE SHEET
Model: Monitor/TV/Large TV Inverter(s)
MONITOR INVERTER

Model: 20" 6 CCFL Inverter
Input Voltage: 19V +- 10%
Efficiency: 85%~95%
Lamp Current: 4 mA
L x W x H= 170 * 60 * 18

Model: 17" & 19" 4 CCFL Inverter
Input Voltage: 12V +- 10%
Efficiency: 85%~95%
Lamp Current: 4 mA
L x W x H= 178 * 30 * 15
LCD TV INVERTER

Model: 21.3" 6U CCFL Inverter
Input Voltage: 12V +- 10%
Efficiency: 85%~95%
Lamp Current: 6 mA
L x W x H= 290 * 96 * 14


Model: 32" 14 CCFL Inverter
Input Voltage: 24V +- 10%
Efficiency: 80%~90%
Lamp Current: 5.5 mA
L x W x H= 290 * 96 * 14 ( Master)/365* 45*15 ( Slave)

Model: 32" 16 CCFL Inverter
Input Voltage: 12V +- 10%
Efficiency: 85%~95%
Lamp Current: 4 mA
L x W x H= 320 * 75 * 18


Model: 32" 16 CCFL Inverter
Input Voltage: 24V +- 10%
Efficiency: 80%~90%
Lamp Current: 4.5 mA
L x W x H= 320 * 80 * 15 ( Master) / 365* 35* 15 (Slave)
